All Products >> Product Category >> Insulation Displacement Connectors (Wire-to-Board type) >Product Series >> CZW connector (CZ family)
Series Description
1.5 mm pitch insulation displacement type CZ connector, holder for making that socket connector in dual-row, and the variety of header for them can support rationalization of manufacturing the complicated harnesses and high density of mounting on PCB.
To purchase this product, find a distributor or representative in your area. You can also request a free sample. If you have questions, call (800) 947-1110.
Pitch | 1.5mm |
Current Rating | 2 A (AWG #26) |
Voltage Rating | 100V |
Connection variations (Compatibility | Compatible crimp connector available |
Lock | Friction lock |
Mating direction | Top entry, Side entry |
PC board mounting | DIP (Through-hole), SMT |
Qualitative features | Small and space saving, Low profile |
Standard | UL, CSA |
