All Products >> Product Category >> Wire-to-Wire Connectors >Product Series >> TZW connector (CZ family)
Product Photo
Schematic
Series Description
These are the single-row/Dual-row units to connect each socket among the insulation displacement type CZ/CZW connectors or the crimp type CZH/CZHW connectors with 1.5 mm pitch. These units improve the degree of freedom in designing the wiring inside the equipment.
To purchase this product, find a distributor or representative in your area. You can also request a free sample. If you have questions, call (800) 947-1110.
| Pitch | 1.5mm |
| Current Rating | 2 A (AWG #26) |
| Voltage Rating | 100V |
| Array (Insertion part) | Dual-row |
| Lock | Friction lock |
| Others | Wire-to-Wire Adapter |
| Panel mounting | Panel lock |
| Standard | UL, CSA |
