Product Series

Wire-to-Board (Crimp Style)

Filter by:

Pitch

Current Rating

Voltage Rating

Close up image of VL Connector

VL Connector

Pitch (mm)

6.2

Current Rating (A)

20

Voltage Rating (V)

600

Features

With secure locking device
Close up image of PSI Connector

PSI Connector

Pitch (mm)

4

Current Rating (A)

12

Voltage Rating (V)

300

Features

High electric current capacity
Close up image of VH Connector

VH Connector

Pitch (mm)

3.96

Current Rating (A)

10

Voltage Rating (V)

250

Features

With secure locking device
Close up image of XNI Connector

XNI Connector

Pitch (mm)

2.5

Current Rating (A)

3

Voltage Rating (V)

250

Features

With secure locking device, With an inertia lock mechanism
Close up image of PNI Connector

PNI Connector

Pitch (mm)

2

Current Rating (A)

3

Voltage Rating (V)

100

Features

With secure locking device, With an inertia lock mechanism
Close up image of JFA connector Connector kits for motor

JFA connector Connector kits for motor

Pitch (mm)

Current Rating (A)

Voltage Rating (V)

Close up image of SPF Connector

SPF Connector

Pitch (mm)

Current Rating (A)

5

Voltage Rating (V)

Close up image of SMF Connector

SMF Connector

Pitch (mm)

Current Rating (A)

5

Voltage Rating (V)

Close up image of SDF Connector

SDF Connector

Pitch (mm)

Current Rating (A)

5

Voltage Rating (V)

Close up image of LBT Connector A Type

LBT Connector A Type

Pitch (mm)

Current Rating (A)

7, 0.5

Voltage Rating (V)

50
Close up image of JFA connector J-PF3 press fit type

JFA connector J-PF3 press fit type

Pitch (mm)

Current Rating (A)

13

Voltage Rating (V)

250
Close up image of JFA Connector (Metal shell)

JFA Connector (Metal shell)

Pitch (mm)

Current Rating (A)

Voltage Rating (V)

Features

Waterproof
Close up image of CN Connector (W to B)

CN Connector (W to B)

Pitch (mm)

1

Current Rating (A)

Voltage Rating (V)

250
Close up image of AUH Connector

AUH Connector

Pitch (mm)

Current Rating (A)

5, 1

Voltage Rating (V)

30

Features

Low-profile
Close up image of BH connector (12.0mm pitch)

BH connector (12.0mm pitch)

Pitch (mm)

12

Current Rating (A)

1

Voltage Rating (V)

600
Close up image of VT Connector

VT Connector

Pitch (mm)

11.88

Current Rating (A)

12

Voltage Rating (V)

250

Features

With secure locking device
Close up image of JFPS Connector

JFPS Connector

Pitch (mm)

8.8

Current Rating (A)

35

Voltage Rating (V)

600

Features

High electric current capacity
Close up image of PSI Connector (High Current Specification D Type)

PSI Connector (High Current Specification D Type)

Pitch (mm)

8

Current Rating (A)

15

Voltage Rating (V)

600

Features

High electric current capacity
Close up image of LV Connector

LV Connector

Pitch (mm)

8

Current Rating (A)

5, 7

Voltage Rating (V)

250
Close up image of BH Connector (8.0mm pitch)

BH Connector (8.0mm pitch)

Pitch (mm)

8

Current Rating (A)

1

Voltage Rating (V)

600
Close up image of VAJ Connector

VAJ Connector

Pitch (mm)

7.92

Current Rating (A)

10

Voltage Rating (V)

250

Features

With secure locking device
Close up image of VA Connector

VA Connector

Pitch (mm)

7.92

Current Rating (A)

7

Voltage Rating (V)

250

Features

With secure locking device
Close up image of VYH Connector

VYH Connector

Pitch (mm)

6.5

Current Rating (A)

15

Voltage Rating (V)

300
Close up image of JFA Connector J4000 Series (W to B 6.35mm pitch)

JFA Connector J4000 Series (W to B 6.35mm pitch)

Pitch (mm)

6.35

Current Rating (A)

20

Voltage Rating (V)

600

Features

With secure locking device, High electric current capacity, High withstanding voltage
Close up image of VL Connector (W to B)

VL Connector (W to B)

Pitch (mm)

6.2

Current Rating (A)

20

Voltage Rating (V)

600

Features

With secure locking device
Close up image of VL Connector (HIGH CURRENT TYPE) (W to B)

VL Connector (HIGH CURRENT TYPE) (W to B)

Pitch (mm)

6.2

Current Rating (A)

23

Voltage Rating (V)

600

Features

With secure locking device
Close up image of JFA Connector J4000 Series (W to B 6.0mm pitch)

JFA Connector J4000 Series (W to B 6.0mm pitch)

Pitch (mm)

6

Current Rating (A)

20

Voltage Rating (V)

600

Features

With secure locking device, High electric current capacity, High withstanding voltage
Close up image of BHT Connector (W to B)

BHT Connector (W to B)

Pitch (mm)

5.1

Current Rating (A)

1

Voltage Rating (V)

1500
Close up image of VB Connector

VB Connector

Pitch (mm)

5.08

Current Rating (A)

7

Voltage Rating (V)

250
Close up image of LC Connector L type

LC Connector L type

Pitch (mm)

5.08

Current Rating (A)

5

Voltage Rating (V)

250
Close up image of LC Connector

LC Connector

Pitch (mm)

5.08

Current Rating (A)

7

Voltage Rating (V)

250
Close up image of JFA Connector J300 series (W to B 5.08mm pitch)

JFA Connector J300 series (W to B 5.08mm pitch)

Pitch (mm)

5.08

Current Rating (A)

15

Voltage Rating (V)

600

Features

With secure locking device, High electric current capacity, High withstanding voltage
Close up image of XL Connector (W to B)

XL Connector (W to B)

Pitch (mm)

5

Current Rating (A)

10

Voltage Rating (V)

150

Features

With secure locking device
Close up image of WPJ Connector (W to B)

WPJ Connector (W to B)

Pitch (mm)

5

Current Rating (A)

7

Voltage Rating (V)

300

Features

Waterproof
Close up image of V Connector

V Connector

Pitch (mm)

5

Current Rating (A)

5

Voltage Rating (V)

250
Close up image of SV Connector

SV Connector

Pitch (mm)

5

Current Rating (A)

5

Voltage Rating (V)

250
Close up image of NV Connector

NV Connector

Pitch (mm)

5

Current Rating (A)

10

Voltage Rating (V)

250

Features

With secure locking device
Close up image of HYV Connector

HYV Connector

Pitch (mm)

5

Current Rating (A)

10

Voltage Rating (V)

300

Features

With an inertia lock mechanism
Close up image of DV Connector

DV Connector

Pitch (mm)

5

Current Rating (A)

5

Voltage Rating (V)

250

Features

With secure locking device
Close up image of JWPS Connector (W to B)

JWPS Connector (W to B)

Pitch (mm)

4

Current Rating (A)

4, 5, 6

Voltage Rating (V)

300

Features

With secure locking device, Waterproof
Close up image of BH Connector (4.0mm pitch)

BH Connector (4.0mm pitch)

Pitch (mm)

4

Current Rating (A)

1

Voltage Rating (V)

600
Close up image of VU Connector

VU Connector

Pitch (mm)

3.96

Current Rating (A)

5

Voltage Rating (V)

250

Features

With secure locking device
Close up image of VH Connector (High box type)

VH Connector (High box type)

Pitch (mm)

3.96

Current Rating (A)

7, 10

Voltage Rating (V)

250

Features

With secure locking device
Close up image of HL Connector (W to B)

HL Connector (W to B)

Pitch (mm)

3.96

Current Rating (A)

7

Voltage Rating (V)

300

Features

With secure locking device
Close up image of JFA Connector J300 series (W to B 3.81mm pitch)

JFA Connector J300 series (W to B 3.81mm pitch)

Pitch (mm)

3.81

Current Rating (A)

15

Voltage Rating (V)

250

Features

With secure locking device, High electric current capacity, High withstanding voltage
Close up image of BHS Connector (W to B)

BHS Connector (W to B)

Pitch (mm)

3.5

Current Rating (A)

1

Voltage Rating (V)

1400
Close up image of BD Connector (3.5mm pitch)

BD Connector (3.5mm pitch)

Pitch (mm)

3.5

Current Rating (A)

1

Voltage Rating (V)

1400

Features

With secure locking device
Close up image of BNI Connector

BNI Connector

Pitch (mm)

3.3

Current Rating (A)

4

Voltage Rating (V)

300

Features

With an inertia lock mechanism
Close up image of RF Connector

RF Connector

Pitch (mm)

2.54

Current Rating (A)

2

Voltage Rating (V)

250
Close up image of RE Connector

RE Connector

Pitch (mm)

2.54

Current Rating (A)

2

Voltage Rating (V)

250
Close up image of RA Connector crimp style

RA Connector crimp style

Pitch (mm)

2.54

Current Rating (A)

1

Voltage Rating (V)

300
Close up image of XM Connector (High box type)

XM Connector (High box type)

Pitch (mm)

2.5

Current Rating (A)

3

Voltage Rating (V)

250

Features

With secure locking device
Close up image of XH Connector (High box type)

XH Connector (High box type)

Pitch (mm)

2.5

Current Rating (A)

3

Voltage Rating (V)

250
Close up image of XH Connector

XH Connector

Pitch (mm)

2.5

Current Rating (A)

3

Voltage Rating (V)

250
Close up image of XAG Connector

XAG Connector

Pitch (mm)

2.5

Current Rating (A)

3

Voltage Rating (V)

250

Features

Low-profile, With secure locking device
Close up image of XAD Connector (W to B)

XAD Connector (W to B)

Pitch (mm)

2.5

Current Rating (A)

3

Voltage Rating (V)

250

Features

With secure locking device
Close up image of XA Connector (W to B)

XA Connector (W to B)

Pitch (mm)

2.5

Current Rating (A)

3

Voltage Rating (V)

250

Features

With secure locking device
Close up image of XA connector (High box type)

XA connector (High box type)

Pitch (mm)

2.5

Current Rating (A)

3

Voltage Rating (V)

250

Features

With secure locking device
Close up image of TSF connector

TSF connector

Pitch (mm)

2.5

Current Rating (A)

3

Voltage Rating (V)

50
Close up image of PXA Connector

PXA Connector

Pitch (mm)

2.5

Current Rating (A)

3

Voltage Rating (V)

250

Features

With secure locking device
Close up image of NH Connector

NH Connector

Pitch (mm)

2.5

Current Rating (A)

3

Voltage Rating (V)

250
Close up image of LEX Connector

LEX Connector

Pitch (mm)

2.5

Current Rating (A)

3

Voltage Rating (V)

300

Features

For LED lamp
Close up image of JFA Connector J2000 series (W to B)

JFA Connector J2000 series (W to B)

Pitch (mm)

2.5

Current Rating (A)

4.6

Voltage Rating (V)

250

Features

With secure locking device, High electric current capacity, High withstanding voltage
Close up image of HR Connector (Crimp style)

HR Connector (Crimp style)

Pitch (mm)

2.5

Current Rating (A)

3

Voltage Rating (V)

250
Close up image of EH Connector

EH Connector

Pitch (mm)

2.5

Current Rating (A)

3

Voltage Rating (V)

250
Close up image of BHL Connector

BHL Connector

Pitch (mm)

2.3

Current Rating (A)

1

Voltage Rating (V)

1400
Close up image of JFA Connector J1000 Series (W to B)

JFA Connector J1000 Series (W to B)

Pitch (mm)

2.2

Current Rating (A)

6.4

Voltage Rating (V)

125

Features

With secure locking device
Close up image of SFV Connector

SFV Connector

Pitch (mm)

2

Current Rating (A)

1

Voltage Rating (V)

300

Features

High withstanding voltage
Close up image of PUD Connector

PUD Connector

Pitch (mm)

2

Current Rating (A)

3

Voltage Rating (V)

250

Features

With secure locking device
Close up image of PNI Connector (High box type)

PNI Connector (High box type)

Pitch (mm)

2

Current Rating (A)

3

Voltage Rating (V)

100
Close up image of PND Connector

PND Connector

Pitch (mm)

2

Current Rating (A)

3

Voltage Rating (V)

250

Features

With secure locking device
Close up image of PLI Connector

PLI Connector

Pitch (mm)

2

Current Rating (A)

3

Voltage Rating (V)

100

Features

With an inertia lock mechanism
Close up image of PID Connector

PID Connector

Pitch (mm)

2

Current Rating (A)

3

Voltage Rating (V)

250
Close up image of PHD Connector

PHD Connector

Pitch (mm)

2

Current Rating (A)

3

Voltage Rating (V)

250
Close up image of PH Connector (High box type)

PH Connector (High box type)

Pitch (mm)

2

Current Rating (A)

2

Voltage Rating (V)

100
Close up image of PH Connector

PH Connector

Pitch (mm)

2

Current Rating (A)

2

Voltage Rating (V)

100
Close up image of PBV Connector

PBV Connector

Pitch (mm)

2

Current Rating (A)

3

Voltage Rating (V)

100

Features

With secure locking device
Close up image of PBD connector

PBD connector

Pitch (mm)

2

Current Rating (A)

3

Voltage Rating (V)

100

Features

With secure locking device
Close up image of PAD Connector

PAD Connector

Pitch (mm)

2

Current Rating (A)

3

Voltage Rating (V)

250

Features

With secure locking device
Close up image of PA Connector (High box type)

PA Connector (High box type)

Pitch (mm)

2

Current Rating (A)

3

Voltage Rating (V)

250, 100
Close up image of PA Connector

PA Connector

Pitch (mm)

2

Current Rating (A)

3

Voltage Rating (V)

250, 100

Features

With secure locking device
Close up image of JWPF Connector (W to B)

JWPF Connector (W to B)

Pitch (mm)

2

Current Rating (A)

3

Voltage Rating (V)

100

Features

With secure locking device, Waterproof
Close up image of SFK Connnector

SFK Connnector

Pitch (mm)

1.8

Current Rating (A)

4

Voltage Rating (V)

350

Features

High withstanding voltage
Close up image of SFH Connector

SFH Connector

Pitch (mm)

1.8

Current Rating (A)

4

Voltage Rating (V)

350

Features

High withstanding voltage
Close up image of LEA Connector

LEA Connector

Pitch (mm)

1.8

Current Rating (A)

3

Voltage Rating (V)

300

Features

For LED lamp
Close up image of ZPD Connector

ZPD Connector

Pitch (mm)

1.5

Current Rating (A)

2, 1.5

Voltage Rating (V)

100

Features

With secure locking device
Close up image of ZND Connector

ZND Connector

Pitch (mm)

1.5

Current Rating (A)

2

Voltage Rating (V)

100

Features

With secure locking device
Close up image of ZH Connector

ZH Connector

Pitch (mm)

1.5

Current Rating (A)

1

Voltage Rating (V)

50
Close up image of ZE Connector

ZE Connector

Pitch (mm)

1.5

Current Rating (A)

2

Voltage Rating (V)

100

Features

With secure locking device
Close up image of RTZ Connector

RTZ Connector

Pitch (mm)

1.5

Current Rating (A)

2

Voltage Rating (V)

50
Close up image of CZH/CZHW Connector

CZH/CZHW Connector

Pitch (mm)

1.5

Current Rating (A)

2

Voltage Rating (V)

100
Close up image of ADH Connector

ADH Connector

Pitch (mm)

1.3

Current Rating (A)

3

Voltage Rating (V)

30

Features

Low-profile
Close up image of GVH Connector

GVH Connector

Pitch (mm)

1.25

Current Rating (A)

1

Voltage Rating (V)

50
Close up image of GHD Connector (Tin-plated product)

GHD Connector (Tin-plated product)

Pitch (mm)

1.25

Current Rating (A)

1.25, 1

Voltage Rating (V)

50

Features

With secure locking device
Close up image of GHD Connector (Gold-plated product)

GHD Connector (Gold-plated product)

Pitch (mm)

1.25

Current Rating (A)

1

Voltage Rating (V)

50

Features

With secure locking device
Close up image of GH Connector

GH Connector

Pitch (mm)

1.25

Current Rating (A)

1

Voltage Rating (V)

50

Features

With secure locking device
Close up image of GEZ Connector

GEZ Connector

Pitch (mm)

1.25

Current Rating (A)

1.5, 1, 0.8

Voltage Rating (V)

50

Features

With secure locking device
Close up image of AGH Connector

AGH Connector

Pitch (mm)

1.25

Current Rating (A)

1

Voltage Rating (V)

50
Close up image of ACHL Connector

ACHL Connector

Pitch (mm)

1.2

Current Rating (A)

2

Voltage Rating (V)

50

Features

Low-profile
Close up image of ACHF Connector

ACHF Connector

Pitch (mm)

1.2

Current Rating (A)

2.5

Voltage Rating (V)

50

Features

Low-profile
Close up image of ACH Connector

ACH Connector

Pitch (mm)

1.2

Current Rating (A)

2

Voltage Rating (V)

50

Features

For LED lamp
Close up image of SFG Connector

SFG Connector

Pitch (mm)

1.1

Current Rating (A)

1

Voltage Rating (V)

200

Features

High withstanding voltage
Close up image of SHLV Connector

SHLV Connector

Pitch (mm)

1

Current Rating (A)

1

Voltage Rating (V)

30

Features

With secure locking device
Close up image of SHLD Connector

SHLD Connector

Pitch (mm)

1

Current Rating (A)

1

Voltage Rating (V)

50

Features

With secure locking device
Close up image of SHL Connector

SHL Connector

Pitch (mm)

1

Current Rating (A)

1

Voltage Rating (V)

50
Close up image of SHJ Connector

SHJ Connector

Pitch (mm)

1

Current Rating (A)

1

Voltage Rating (V)

125

Features

Low-profile
Close up image of SHD Connector

SHD Connector

Pitch (mm)

1

Current Rating (A)

1

Voltage Rating (V)

50
Close up image of SH Connector

SH Connector

Pitch (mm)

1

Current Rating (A)

1

Voltage Rating (V)

50
Close up image of NSHD Connector

NSHD Connector

Pitch (mm)

1

Current Rating (A)

1

Voltage Rating (V)

50

Features

With secure locking device
Close up image of NSH Connector

NSH Connector

Pitch (mm)

1

Current Rating (A)

1

Voltage Rating (V)

50

Features

With secure locking device
Close up image of CSH Connector

CSH Connector

Pitch (mm)

1

Current Rating (A)

2

Voltage Rating (V)

50
Close up image of APSH Connector

APSH Connector

Pitch (mm)

1

Current Rating (A)

1

Voltage Rating (V)

50

Features

With secure locking device
Close up image of SUH Connector

SUH Connector

Pitch (mm)

0.8

Current Rating (A)

1

Voltage Rating (V)

30
Close up image of FWG Connector

FWG Connector

Pitch (mm)

0.5

Current Rating (A)

0.3

Voltage Rating (V)

50

Features

Low-profile, High-speed transmission
JST footer logo JST footer logo JST footer logo

North American Headquarters

JST Sales America, Inc.
1957 S. Lakeside Drive
Waukegan, IL 60085 USA
(847) 473-1957
Products Innovation Resources About Contact

Copyright © 2021 JST Sales America, Inc. All rights reserved.
Privacy Policies | Quality Policy | Conflict Minerals Policy | Terms of Use
